Kia K9 II (2018-2021) vacm pump sig out Wiring diagram
This page shows the only wiring diagram for the component.vacm pump sig out, which is found in the car Kia K9 II (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vacm pump sig out (1 of 1)
AUTO HOLD SW SIG IN
BLK WIRE
BLU WIRE
BRK LIGHT SW
BRN WIRE
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
E/R-F
EPB ACTUATOR
ESC 1 FUSE
ESC 2 FUSE
ESC 3 FUSE
ESC OFF SW SIG IN
ESC UNIT ESC CONTROL MODULE
FL SIG
FL VCC
FR SIG
FR VCC
GRN WIRE
HOT AT ALL TIMES
LEFT FRONT WHEEL SPEED SENSOR
LEFT REAR WHEEL SENSOR (LEFT REAR WHEEL HUB ASSEMBLY)
LR MOC MOTOR(+)
LR WHEEL SENS SIG
LR WHEEL SENS VCC
MTR MONITORING
MULTI FUSE 1
NCA WIRE
ON/START INPUT
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PCB BLOCK
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT FRONT WHEEL SPEED SENSOR
RIGHT REAR WHEEL SENSOR (RIGHT REAR WHEEL HUB ASSEMBLY)
RR MOC MOTOR(+)
RR WHEEL SENS SIG
RR WHEEL SENS VCC
SENSOR 4 FUSE
VACM PUMP SIG OUT
VACM SW SIG IN
VACUUM PUMP IN
VBATT MTR RLY
VR ACTUATION
W/ ECS
WHEEL SENS OUT (RR)
WHEEL SENSOR
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (1 of 3) -> VACM PUMP SIG OUT
