Kia K9 II (2018-2021) ind pdw switch Wiring diagram
This page shows the only wiring diagram for the component.ind pdw switch, which is found in the car Kia K9 II (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ind pdw switch (1 of 1)
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
FRONT CONSOLE SWITCH
GRN WIRE
GRY WIRE
HOT W/
IBU
ICU JUNCTION BLOCK
ICU-E
ILL
IND PDW SWITCH
LEFT FORWARD PARKING DISTANCE WARNING
LEFT FORWARD PARKING DISTANCE WARNING (CENTER)
LIN PDW
MODULE 6 FUSE
ORG/ WIRE
PDW (F/R) POWER IN
PDW SWITCH IN
PDW SWITCH IND
PNK WIRE
RIGHT FORWARD PARKING DISTANCE WARNING
RIGHT FORWARD PARKING DISTANCE WARNING (CENTER)
WHT WIRE
WHT/BLK WIRE
Go to component -> Parking assistant circuit (1 of 2) -> IND PDW SWITCH
