Kia K9 II (2018-2021) battery junction block battery Wiring diagram
This page shows the only wiring diagram for the component.battery junction block battery, which is found in the car Kia K9 II (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram battery junction block battery (1 of 1)
6:4 SEAT
8 WAY
BATTERY JUNCTION BLOCK BATTERY
BENCH SEAT
BENCH SEAT 6:4 SEAT
BLK WIRE
BLU WIRE
DRIVER CCS MODULE
DRIVER DOOR LOCK ACTUATOR
DRIVER DOOR MODULE
DRIVER DOOR MOOD LAMP
DRIVER DOOR MOOD POCKET LAMP
DRIVER DOOR PAWL SWITCH
DRIVER IMS SWITCH
DRIVER POWER DOOR LATCH
DRIVER POWER OUTSIDE MIRROR
DRIVER POWER SEAT MODULE
DRIVER POWER SEAT SWITCH
DRIVER POWER WINDOW MODULE
DRIVER SEAT MOOD LAMP
DRIVER SEAT RELAY MODULE
DRIVER SEAT WARMER CONTROL MODULE
DRIVER SMART KEY OUTSIDE HANDLE
GRY WIRE
LEFT REAR DOOR LOCK ACTUATOR
LEFT REAR DOOR MODULE
LEFT REAR DOOR MOOD LAMP
LEFT REAR DOOR MOOD POCKET LAMP
LEFT REAR DOOR PAWL SWITCH
LEFT REAR POWER DOOR LATCH
LEFT REAR POWER SEAT SWITCH
LEFT REAR POWER WINDOW MODULE
LEFT REAR SEAT CCS MODULE
LEFT REAR SEAT RELAY MODULE
LEFT REAR SEAT WARMER CONTROL MODULE
LEFT REAR SMART KEY OUTSIDE HANDLE
NCA WIRE
POWER TRUNK MODULE
POWER TRUNK MODULE BUZZER
REAR SEAT CONSOLE LAMP
SUNROOF CONTROL UNIT (GLASS)
TRUNK LID LATCH
W/ CCS
W/ MEMORY
W/O CCS
W/O MEMORY
W/O POWER TRUNK MODULE
Go to component -> Ground distribution circuit (1 of 7) -> BATTERY JUNCTION BLOCK BATTERY
