Kia K9 II (2018-2021) b-can stop high lp sw Wiring diagram
This page shows the only wiring diagram for the component.b-can stop high lp sw, which is found in the car Kia K9 II (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram b-can stop high lp sw (1 of 1)
ASIC
B-CAN LOW
B-CAN STOP HIGH LP SW
BLK WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRAKE SWITCH FUSE
BRN WIRE
C-CAN TRANSCEIVER
CLUSTER FUSE
COIL
COMPUTER DATA LINES SYSTEM
DIMMING CIRCUIT
ESC CONTROL MODULE
FULL TFT
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
ICU JUNCTION BLOCK
ICU-C
ICU-F
ICU-G
INSTRUMENT CLUSTER
INTERFACE
IPS CONTROL MODULE
LEAK CURRENT AUTO CUT DEVICE
LEFT TURN IND
MAIN POWER BLOCK
MEMORY 1 FUSE
MEMORY PWR
MICOM
MODULE 5 FUSE
MULTI MEDIA 4 FUSE
ON/START INPUT
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
REG
RIGHT TURN IND
SIG 1 GND
STOP LAMP SWITCH
STOP LP SIG
STOP SIG
TAIL ON IND
TFT LCD DRIVE
W/ ISG W/O ISG
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (4 of 4) -> B-CAN STOP HIGH LP SW
