Kia K9 II (2018-2021) auto stop ind Wiring diagram
This page shows the only wiring diagram for the component.auto stop ind, which is found in the car Kia K9 II (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto stop ind (1 of 1)
ABS IND.
AFS IND
AIR BAG
AIR BAG IND
AMP IC
AUTO HIGH BEAM IND
AUTO STOP IND
BLK WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
C-CAN TRANSCEIVER
CHARGE IND
CLUSTER FUSE
COAXIAL CABLE
COMPUTER DATA LINES SYSTEM
CONSTANT CURRENT
CRUISE CONTROL SYSTEM
DESERIALIZER
DETENT OUT
DIAL
DIMMING SDRAM CIRCUIT
DRV MODE SW I/P
ENGINE CHECK IND
EPB IND
ESC IND
ESC OFF IND
FCA IND
FUEL GAUGE
FUEL SENDER I/P (-)
GRAPHIC MEMORY
GRN WIRE
GRY WIRE
HIGH BEAM IND
HOT W/
ICU JUNCTION BLOCK
ICU-F
ILL (-) OUT
ILLUMINATION
IMMO IND
INSTRUMENT CLUSTER
INTERFACE
LED HEADLAMP IND
LEFT TURN IND
LOW BEAM IND
LOW FUEL IND
M-CAN TRANSCEIVER
MASTER WARNING IND
MDPS IND
MICOM
NAVIGATION SYSTEM
OIL PRESSURE IND
OVER SPEED IND
PARKING BRAKE IND.
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
REG
RHEO DOWN IN
RHEO UP IN
RIGHT TURN IND
RR VIEW CAM SW I/P
SEAT BELT IND
SEG LCD
SIG 1 GND
SIG 3 GND
SPD OUT (+)
SPEED METER
SUPPLEMENTAL RESTRAINTS SYSTEM
SURROUND VIEW MONITOR UNIT
SVM I/P
TACHOMETER
TAIL ON IND
TEMP GAUGE
TFT LCD (7 INCH)
TFT LCD DRIVER
TPMS TREAD IND
TRIP SW (-) I/P
TRIP SW 2 I/P (+)
VIDEO SIG
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit, 7 inch tft display (1 of 3) -> AUTO STOP IND
