Car Wiring Diagrams for Cooling fan circuit for Kia K7 II (2016-2021)

A/C PRESSURE TRANSDUCER B+5 FUSE BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COOLING FAN 1 RELAY COOLING FAN 2 FUSE COOLING FAN 2 RELAY COOLING FAN MOTOR E/R JUNCTION BLOCK E/R-B E/R-C E/R-D ECTS GROUND ECTS SIGNAL ECU 2 FUSE ENGINE CONTROL RELAY ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR ENGINE CTRL RELAY CTRL GRN WIRE GRN/BLK WIRE HOT AT ALL TIMES MEMORY POWER MULTI FUSE (TYPE B) NCA WIRE ORG/ WIRE P-CAN HIGH P-CAN LOW PCB BLOCK PNK WIRE RED WIRE RELAY CTRL 2 RELAY CTRL 3 SENS GND SENS PWR SENS SIG SENSOR 2 FUSE WHT WIRE WHT/BLK WIRE YEL WIRE
