Kia K7 II (2016-2021) rear door right sig lock/unlock Wiring diagrams

This page contains all the electrical diagrams for the component. rear door right sig lock/unlock, in which he is found in the car Kia K7 II (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram rear door right sig lock/unlock (1 of 3)

Wiring diagram rear door right sig lock/unlock for Kia K7 II (2016-2021) (1 of 3)

Get access

B-CAN HIGH B-CAN LOW BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DOOR LOCK DOOR LOCK FUSE DOOR LOCK RELAY DOOR LOCK RLY CTRL DOOR SWITCH DOOR UNLOCK DOOR UNLOCK RELAY DOOR UNLOCK RLY CTRL GATEWAY GRN WIRE GRY WIRE HOT AT ALL TIMES I/P-B I/P-E I/P-F IGPM IPS CONTROL MODULE LEFT REAR DOOR LOCK ACTUATOR ORG/ WIRE PNK WIRE REAR DOOR LEFT SIG LOCK/UNLOCK REAR DOOR LEFT SIG SWITCH REAR DOOR RIGHT SIG LOCK/UNLOCK REAR DOOR RIGHT SIG SWITCH RIGHT REAR DOOR LOCK ACTUATOR VARISTOR WHT WIRE YEL WIRE

Go to component -> Forced entry circuit (3 of 3) -> REAR DOOR RIGHT SIG LOCK/UNLOCK

Wiring diagram rear door right sig lock/unlock (2 of 3)

Wiring diagram rear door right sig lock/unlock for Kia K7 II (2016-2021) (2 of 3)

Get access

BLK WIRE BLU WIRE BRN WIRE DOOR LOCK FUSE DOOR LOCK RELAY DOOR LOCK RELAY CTRL DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR UNLOCK RELAY DOOR UNLOCK RELAY CTRL FROM B+1 FUSE (DIAGRAM 1 OF 2) FROM B+4 FUSE (DIAGRAM 1 OF 2) GRN WIRE GRN/ORG WIRE GRY WIRE GRY/ORG WIRE I/P-A I/P-B I/P-D I/P-E I/P-F IGPM INTERIOR LIGHTS, TRUNK, TAILGATE, FUEL DOORS SYSTEMS IPS CONTROL MODULE LEAK CURRENT AUTO CUT DEVICE LEAK CURRENT AUTO CUT RELAY LEAK CURRENT AUTO CUT SWITCH LH TELLTAIL H/LP LOW LH TELLTAIL T/SIG LR REAR WINDOW WINDOW SWITCH SWITCH LOCK SIG SIG DOWN LR WINDOW SWITCH SIG UP MCU (GND) OFF ORG/ WIRE PNK WIRE POWER DISTRIBUTION SYSTEM POWER WINDOWS SYSTEM REAR DOOR LEFT SIG LOCK/UNLOCK REAR DOOR LEFT SIG SWITCH REAR DOOR RIGHT SIG LOCK/UNLOCK REAR DOOR RIGHT SIG SWITCH RED WIRE RH TELLTAIL T/SIG RR WINDOW SWITCH SIG DOWN RR WINDOW SWITCH SIG UP TAILGATE) TELLTAIL H/LP LOW TRUNK FUSE TRUNK LID LOCK HANDLE SWITCH SWITCH TRUNK LID MAIN SWITCH TRUNK LID OUTSIDE HANDLE SWITCH TRUNK LID RELAY CTRL TRUNK RELAY TRUNK ROOM LAMP TRUNK, TAILGATE, FUEL DOORS SYSTEM WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Ips control module circuit (2 of 2) -> REAR DOOR RIGHT SIG LOCK/UNLOCK
