Kia K7 II (2016-2021) pnk headlamp low sig Wiring diagrams
This page contains all the electrical diagrams for the component. pnk headlamp low sig, in which he is found in the car Kia K7 II (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pnk headlamp low sig (1 of 2)
AFLS IND
AUTO HEADLAMP LEVELING DEVICE MODULE
AUTO HIGH BEAM IND
AUTO LIGHT SENS
AUTO LIGHT SENSOR
AUTO LIGHT, PHOTO SENSOR
B+2 FUSE
B+3 FUSE
B-CAN HIGH
B-CAN LOW
BCM (RIGHT SIDE OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
C-CAN
COMPUTER DATA LINES SYSTEM
DRL
E/R JUNCTION BLOCK
ENGINE COMPT)
FOG LAMP
FRONT FOG IND
GREEN DIMMING CIRCUIT
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HEADLAMP
HI SW IN
HIGH BEAM IND
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INTERFACE
LEFT HEADLAMP
LIGHT SW SIG
LOW BEAM IND
MICOM
MULTI FUSE (TYPE A)
NCA WIRE
PARKING BRAKE IND.
PNK HEADLAMP LOW SIG WIRE
PNK WIRE
POWER
RED WIRE
RIGHT HEADLAMP
SIG
SIG 1 GND
SUPERVISION
SW INPUT
TAIL ON IND
TRANSCEIVER/
W/ LED
W/O LED
WHT WIRE
WHT/BLK WIRE
WIPER, LIGHT GND
YEL WIRE
Go to component -> Autolamps circuit (2 of 2) -> PNK HEADLAMP LOW SIG WIRE
Wiring diagram pnk headlamp low sig (2 of 2)
