Kia K7 II (2016-2021) left audio remote control switch steering wheel Wiring diagram
This page shows the only wiring diagram for the component.left audio remote control switch steering wheel, which is found in the car Kia K7 II (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left audio remote control switch steering wheel (1 of 1)
A/C SWITCH
A/V, NAVIGATION HEAD UNIT
ANALOG CLOCK
ATM SHIFT LEVER INDICATOR
AUX, USB JACK
B+3 FUSE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
CLOCK- SPRING
CONSOLE SWITCH
DETENT
DRIVER IMS SWITCH
E/R JUNCTION BLOCK
FRONT AIR VENTILATION SEAT CONTROL MODULE
FRONT SEAT WARMER CONTROL MODULE
FRONT TRAY MOOD LAMP
FUEL FILLER, TRUNK OPEN SWITCH
GRY WIRE
HAZARD LAMP SWITCH
HOT AT ALL TIMES
LEFT AUDIO REMOTE CONTROL SWITCH STEERING WHEEL
LEFT REAR POWER WINDOW SWITCH
MULTI FUSE (TYPE A)
NCA WIRE
ORG/ WIRE
OVERHEAD CONSOLE LAMP
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/BLK WIRE
RIGHT REAR POWER WINDOW SWITCH
RIGHT TRIP REMOTE CONTROL SWITCH
TRUNK LOCK SWITCH
USB CHARGER
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> LEFT AUDIO REMOTE CONTROL SWITCH STEERING WHEEL
