Kia K7 II (2016-2021) hazard turn lamp lamp switch switch ind signal Wiring diagram
This page shows the only wiring diagram for the component.hazard turn lamp lamp switch switch ind signal, which is found in the car Kia K7 II (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hazard turn lamp lamp switch switch ind signal (1 of 1)
B+1 FUSE
B+2 FUSE
B+4 FUSE
B/UP LAMP GND
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRAKE OIL LEVEL SIGNAL
BRN/ORG WIRE
BURGLAR ALARM HORN RELAY
DEFOGGER RELAY CONTROL
DEFOGGER SYSTEM
DOOR LOCKS, ANTI-THEFT SYSTEMS
DRIVER SEAT BELT
E/R JUNCTION BLOCK
GND (FOG LAMP)
GND (H/LP LED OPT)
GND (H/LP LED T/SIG OPT)
GRN WIRE
GRN/BLK WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HAZARD LAMP HEADLAMP SWITCH LOW SIGNAL SIGNAL
HAZARD TURN LAMP LAMP SWITCH SWITCH IND SIGNAL
HEADLIGHTS SYSTEM
HOOD SWITCH
HOT AT ALL TIMES
I/P-A
I/P-B
I/P-C
I/P-F
IGPM
INSTRUMENT CLUSTER SYSTEM
IPS CONTROL MODULE
LEFT TURN SIG ACT FRT
MCU (GND)
MEMORY POWER
MULTI FUSE (TYPE A)
MULTI FUSE (TYPE B)
NCA WIRE
ORG/ WIRE
PARKING BRAKE SWITCH
PASSENGER SEAT BELT
PNK/BLK WIRE
RED WIRE
RED/BLK WIRE
RIGHT TURN SIG ACT FRT
STOP LAMP
SUPPLEMENTAL RESTRAINTS SYSTEM
TO IGPM (DIAGRAM 2 OF 2)
WHT WIRE
WHT/BLK WIRE
Go to component -> Ips control module circuit (1 of 2) -> HAZARD TURN LAMP LAMP SWITCH SWITCH IND SIGNAL
