Kia K7 II (2016-2021) backup lp sig Wiring diagrams
This page contains all the electrical diagrams for the component. backup lp sig, in which he is found in the car Kia K7 II (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram backup lp sig (1 of 2)
B/UP LAMP FUSE
BACKUP LAMP
BACKUP LP SIG
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
E/R-D
E/R-F
ELECTROCHROMIC MIRROR
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT IN ON OR START
LEFT REAR COMBINATION LAMP (IN)
NCA WIRE
ON/START INPUT B/UP
ORG/ WIRE
PCB BLOCK
PNK WIRE
PNK/BLK WIRE
RIGHT REAR COMBINATION LAMP (IN)
SIG (1)
SIG (2)
TCM
TCU 2 FUSE
TRANSAXLE RANGE SWITCH
TRANSAXLE RNG
TRANSAXLE RNG SW GND
Go to component -> Backup lamps circuit -> BACKUP LP SIG
Wiring diagram backup lp sig (2 of 2)
A/V, NAVIGATION HEAD UNIT
BACKUP LP SIG
BLK WIRE
BLU WIRE
BODY
ELECTROCHROMIC MIRROR
GRN WIRE
GROUND
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HOT AT ALL TIMES IGPM
HOT IN ON OR START
I/P-D
KEY PAD GND
KEY PAD SIG
KEYPAD
MODULE 6 FUSE
MTS KEY PAD SIG
NAVIGATION, SOUND SYSTEMS
ON/START INPUT
PCB
PHONE
PNK WIRE
RED WIRE
REMOTE CTRL SW GND
SOS
UNIT)
UVO
Go to component -> Electrochromic mirror circuit -> BACKUP LP SIG
