Remote smart parking assist circuit for Kia K5 III facelift (2023-2024)

A/V, NAVIGATION HEAD UNIT ACC/ON INPUT ACC/ON OUTPUT ADAS UNIT (LEFT OF HVAC EVAPORATOR ASSEMBLY) BLK WIRE BLU WIRE BRN WIRE C-CAN HIGH C-CAN LOW COAXIAL CABLE COMPUTER DATA LINES SYSTEM DC-DC CONVERTER FRONT CONSOLE SWITCH 1 GRN WIRE HOT W/ ACC RELAY ENERGIZED ICU JUNCTION BLOCK ICU-F ILL LIN (PDW-F) LIN (PDW-R) MODULE 2 FUSE MODULE 4 FUSE MODULE 7 FUSE NCA WIRE ON INPUT ON/START INPUT ORG/ WIRE PDW SW IND PDW SW MODE PDW SWITCH PDW-F PWR PDW-R PWR POC REAR VIEW CAMERA REAR VIEW VIDEO IN REAR VIEW VIDEO OUT RED WIRE RELAY ENERGIZED SURROUND VIEW MONITOR UNIT VIDEO/PWR W/ ISG W/ SVM W/O ISG W/O SVM WHT WIRE YEL WIRE

BLK WIRE GRN WIRE LEFT PARKING DISTANCE WARNING FORWARD SENSOR LEFT PARKING DISTANCE WARNING FORWARD SENSOR (CENTER) LEFT PARKING DISTANCE WARNING REVERSE SENSOR LEFT PARKING DISTANCE WARNING- REVERSE SENSOR (CENTER) LID 1 LID 2 LID 3 RED WIRE RIGHT PARKING DISTANCE WARNING FORWARD SENSOR RIGHT PARKING DISTANCE WARNING FORWARD SENSOR (CENTER) RIGHT PARKING DISTANCE WARNING REVERSE SENSOR RIGHT PARKING DISTANCE WARNING- REVERSE SENSOR (CENTER)
