Wiring diagram engine performance 1.6l turbo, electric oil pump circuit for Kia K5 III facelift (2023-2024)

Wiring diagram engine performance 1.6l turbo, electric oil pump circuit

K5 Kia III facelift (2023-2024): Wiring diagram engine performance 1.6l turbo, electric oil pump circuit

Get access

BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM E/R JUNCTION BLOCK E/R-C ELECTRONIC OIL PUMP HOT AT ALL TIMES MEM PWR MULTI FUSE 2 OIL PUMP 1 FUSE OIL PUMP 2 FUSE ON/START INPUT ORG/ WIRE P-CAN HI P-CAN LO PCB BLOCK RED WIRE RELAY ENERGIZED
