Kia K5 III facelift (2023-2024) transaxle range sw pwr Wiring diagram
This page shows the only wiring diagram for the component.transaxle range sw pwr, which is found in the car Kia K5 III facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transaxle range sw pwr (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CLOCKSPRING
COMPUTER DATA LINES SYSTEM
CRUISE ON/OFF
DCT L-CAN HIGH
DCT L-CAN LOW
DOWN UP
E/R JUNCTION BLOCK
E/R-A
GRN WIRE
GROUP
GRY WIRE
HIGH PRESSURE OIL PUMP MOTOR
HOT AT ALL TIMES
HOT W/
ILL
LEFT PADDLE SHIFT SWITCH (DOWN)
LFA
MEMORY PWR
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PADD DOWN
PADD UP
PCB BLOCK
PNK ON/START INPUT WIRE
PNK WIRE
PT L-CAN HIGH
PT L-CAN LOW
PWR
RED WIRE
RES+
RIGHT PADDLE SHIFT SWITCH (UP)
RIGHT STEERING WHEEL REMOTE CONTROL SWITCH
SCC
SET-
SIG (1)
SIG (2)
STEERING WHEEL)
TCM
TCU 2 FUSE
TCU 5 FUSE
TRANSAXLE RANGE SW GND
TRANSAXLE RANGE SW PWR
TRANSAXLE RANGE SW SIG 1
TRANSAXLE RANGE SW SIG 2
TRANSAXLE RANGE SWITCH
TRIP
VIO WIRE
W/O PADDLE SHIFT
WHT WIRE
YEL WIRE
Go to component -> 2.5l turbo, transmission circuit (1 of 2) -> TRANSAXLE RANGE SW PWR
