Kia K5 III facelift (2023-2024) shrt term load Wiring diagram
This page shows the only wiring diagram for the component.shrt term load, which is found in the car Kia K5 III facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram shrt term load (1 of 1)
ACC/ON INPUT
B+3 FUSE
BCW IND
BLK WIRE
BRN WIRE
C-CAN C-CAN LOW HIGH
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER (AMP)
DRIVER POWER OUTSIDE MIRROR
DRIVER'S DOOR
E/R JUNCTION BLOCK
GRN WIRE
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
ICU JUNCTION BLOCK
ICU-A
ICU-C
ICU-F
ICU-G
IPS 10
IPS 10 CTRL
IPS CONTROL MODULE
L-CAN HIGH
L-CAN LOW
LEFT REAR CORNER RADAR
MEMORY PWR OUTPUT
MODULE 4 FUSE
MULTI FUSE 1
NCA WIRE
ON/START INPUT
ORG/ WIRE
PASSENGER POWER OUTSIDE MIRROR
PNK BCW IND WIRE
PNK WIRE
RED WIRE
RIGHT REAR CORNER RADAR
SHRT TERM LOAD
W/ ISG
W/O ISG
WHT WIRE
YEL WIRE
Go to component -> Blind spot information system circuit -> SHRT TERM LOAD
