Kia K5 III facelift (2023-2024) rear view switch Wiring diagram
This page shows the only wiring diagram for the component.rear view switch, which is found in the car Kia K5 III facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear view switch (1 of 1)
A/V, NAVIGATION HEAD UNIT
ADAS UNIT (LEFT OF HVAC EVAPORATOR ASSEMBLY)
AVN SIG
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
C-CAN
CAMERA DETECT 1
COAXIAL CABLE
COMPUTER DATA LINES SYSTEM
FRONT CONSOLE SWITCH 1 (W/O SURROUND VIEW MONITOR)
GRN WIRE
GRY WIRE
HOT IN ON OR START
ICU JUNCTION BLOCK
ICU-E
ILL
M-CAN HIGH
M-CAN LOW
MODULE 8 FUSE
NCA WIRE
ON/START INPUT
ORG/ WIRE
OUT
PNK WIRE
POC
PWR
REAR CAMERA P GND
REAR CAMERA PWR
REAR CAMERA SHIELD
REAR CAMERA V GND
REAR CAMERA V-SIG
REAR VIEW
REAR VIEW CAMERA
REAR VIEW SWITCH
REAR VIEW VIDEO IN
REAR VIEW VIDEO OUT
RED WIRE
SHIELD
SURROUND VIEW MONITOR UNIT
SW SIG
V GND
V SIG
VIDEO+
VIDEO/PWR
W/ NAVIGATION
W/ SURROUND VIEW MONITOR, PARKING COLLISION AVOIDANCE ASSIST SYSTEM
W/O NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Rear view camera circuit -> REAR VIEW SWITCH
