Kia K5 III facelift (2023-2024) pnk on/start input Wiring diagrams
This page contains all the electrical diagrams for the component. pnk on/start input, in which he is found in the car Kia K5 III facelift (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pnk on/start input (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CLOCKSPRING
COMPUTER DATA LINES SYSTEM
CRUISE ON/OFF
DCT L-CAN HIGH
DCT L-CAN LOW
DOWN UP
E/R JUNCTION BLOCK
E/R-A
GRN WIRE
GROUP
GRY WIRE
HIGH PRESSURE OIL PUMP MOTOR
HOT AT ALL TIMES
HOT W/
ILL
LEFT PADDLE SHIFT SWITCH (DOWN)
LFA
MEMORY PWR
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PADD DOWN
PADD UP
PCB BLOCK
PNK ON/START INPUT WIRE
PNK WIRE
PT L-CAN HIGH
PT L-CAN LOW
PWR
RED WIRE
RES+
RIGHT PADDLE SHIFT SWITCH (UP)
RIGHT STEERING WHEEL REMOTE CONTROL SWITCH
SCC
SET-
SIG (1)
SIG (2)
STEERING WHEEL)
TCM
TCU 2 FUSE
TCU 5 FUSE
TRANSAXLE RANGE SW GND
TRANSAXLE RANGE SW PWR
TRANSAXLE RANGE SW SIG 1
TRANSAXLE RANGE SW SIG 2
TRANSAXLE RANGE SWITCH
TRIP
VIO WIRE
W/O PADDLE SHIFT
WHT WIRE
YEL WIRE
Go to component -> 2.5l turbo, transmission circuit (1 of 2) -> PNK ON/START INPUT WIRE
Wiring diagram pnk on/start input (2 of 2)
12.3 TFT
BLK WIRE
BRN WIRE
C-CAN
C-CAN HIGH
C-CAN LOW
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DISPLAY
E/R JUNCTION BLOCK
HOT AT ALL TIMES
HOT IN ON OR START
ICU JUNCTION BLOCK (LEFT END OF DASH)
ICU-E
INSTRUMENT CLUSTER
MCU
MDPS FUSE
MDPS IND
MDPS UNIT
MEMORY POWER
MULTI FUSE 1
PNK ON/START INPUT WIRE
PNK WIRE
RED WIRE
SIG GND 1
TRANSCEIVER/
W/ 12.3 INCH LCD
WHT WIRE
Go to component -> Electronic power steering circuit, column type -> PNK ON/START INPUT WIRE
