Kia K5 III facelift (2023-2024) left center parking distance warning forward sensor Wiring diagram
This page shows the only wiring diagram for the component.left center parking distance warning forward sensor, which is found in the car Kia K5 III facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left center parking distance warning forward sensor (1 of 1)
ACC RELAY
BLK WIRE
BLK/ORG WIRE
BLOWER RELAY
BRAKE FLUID LEVEL SENSOR
COLUMN TYPE
E/R JUNCTION BLOCK
E/R-A
EXTERNAL BUZZER
HOOD SWITCH
IBU
LEFT CENTER PARKING DISTANCE WARNING FORWARD SENSOR
LEFT CENTER PARKING DISTANCE WARNING REVERSE SENSOR
LEFT PARKING DISTANCE WARNING FORWARD SENSOR
LEFT PARKING DISTANCE WARNING REVERSE SENSOR
MDPS UNIT
MIC SHIELD
OIL LEVEL SENSOR
POWER OUTPUT RELAY
RIGHT CENTER PARKING DISTANCE WARNING FORWARD SENSOR
RIGHT CENTER PARKING DISTANCE WARNING REVERSE SENSOR
RIGHT END OF DASH)
RIGHT PARKING DISTANCE WARNING FORWARD SENSOR
RIGHT PARKING DISTANCE WARNING REVERSE SENSOR
SMART CRUISE CONTROL MODULE
START/STOP BUTTON SWITCH
STOP LAMP SWITCH
SURROUND VIEW MONITOR UNIT
USB JACK
W/ NAVIGATION
W/O NAVIGATION
WIPER HIGH RELAY
WIPER LOW RELAY
Go to component -> Ground distribution circuit (2 of 6) -> LEFT CENTER PARKING DISTANCE WARNING FORWARD SENSOR
