Kia K5 III facelift (2023-2024) grn Wiring diagram
This page shows the only wiring diagram for the component.grn, which is found in the car Kia K5 III facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram grn (131 of 131)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
CMPS (EXHAUST) SIG
CMPS (INTAKE) SIG
E-CVVT 1 FUSE
E-CVVT 3 FUSE
E-CVVT 4 FUSE
E-CVVT MOTOR
E-CVVT RELAY
E-CVVT RELAY "ON" INPUT
E/R JUNCTION BLOCK
ECTS 1 SIG
EWGA PWR
EWGA SIG
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IC IGNITER
IGNITER
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
KNOCK SENSOR
MOTOR
MULTI FUSE 2
OIL TEMPERATURE SIG
ON INPUT
ORG/ WIRE
OXYGEN SENS
OXYGEN SENS UP V-G
OXYGEN SENS UP V-IP
OXYGEN SENS UP V-N
OXYGEN SENS UP V-RC
PNK WIRE
PWR
RED WIRE
SENS GND
SENS PWR
SENS SIG
SENS SUPPLY
SIG
START RELAY
START RELAY (SWITCH)
STARTING/CHARGING SYSTEM
TOP OF ENGINE)
TPS 1 SIG
TPS 2 SIG
TPS SUPPLY
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Wiring diagram engine performance 2.5l turbo, engine controls circuit (3 of 7) -> GRN WIRE
