Kia K5 III facelift (2023-2024) ads glass temp Wiring diagram
This page shows the only wiring diagram for the component.ads glass temp, which is found in the car Kia K5 III facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ads glass temp (1 of 1)
A/C 2 FUSE
A/C CONTROL MODULE
ADS GLASS TEMP
ADS SCL
ADS SDA
AMBIENT TEMP SENS (+)
AUTO DEFOGGER ACTUATOR
AUTO DEFOGGER ACTUATOR CLOSE
AUTO DEFOGGER ACTUATOR F/B
AUTO DEFOGGER ACTUATOR OPEN
BLK WIRE
BLOWER FUSE
BLOWER MOTOR
BLOWER RELAY
BLU WIRE
COMPUTER DATA LINES SYSTEM
DRIVER TEMP ACTUATOR COOL
DRIVER TEMP ACTUATOR F/B
DRIVER TEMP ACTUATOR WARM
E/R JUNCTION BLOCK
EVAPORATOR SENS (+)
FET (FIELD EFFECT TRANSISTOR)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-E
INCAR SENSOR
INTAKE ACTUATOR F/B
INTAKE ACTUATOR FRE
INTAKE ACTUATOR REC
MODE ACTUATOR
MODE ACTUATOR DEF
MODE ACTUATOR F/B
MODE ACTUATOR VENT
MULTI FUSE 1
NCA WIRE
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PASSENGER TEMP ACTUATOR COOL
PASSENGER TEMP ACTUATOR F/B
PASSENGER TEMP ACTUATOR WARM
PNK WIRE
RED WIRE
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (1 of 4) -> ADS GLASS TEMP
