Kia K5 III (2019-2023) sens sply Wiring diagram
This page shows the only wiring diagram for the component.sens sply, which is found in the car Kia K5 III (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sens sply (1 of 1)
A/C 1 FUSE
A/C CONTROL MODULE (ON HVAC BLOWER ASSEMBLY)
A/C SWITCH
ACC/ON INPUT
AMBIENT TEMPERATURE SENSOR
AUTO LIGHT, PHOTO SENSOR
BLK WIRE
BLOWER MOTOR
BLU WIRE
BRN WIRE
DC-DC CONVERTER (AMP)
DC-DC CONVERTER (AUDIO)
DEFOGGER SYSTEM
ECV GND
ECV PWR
FET DRAIN
FET GATE
GRN WIRE
GRY WIRE
HOT W/
HOT W/ ACC RELAY ENERGIZED
HOT W/ LONG TERM LOAD LATCH RELAY ENERGIZED
ICU JUNCTION BLOCK
ICU-B
ICU-E
ICU-F
ILL
ISG B+
MEM PWR OUTPUT
MEMORY FUSE
MEMORY PWR
MODULE 4 FUSE
MODULE 8 FUSE
ON INPUT
ON/START INPUT
ORG/ WIRE
PHOTO SENSOR
PNK WIRE
REAR DEFOGGER SIG
RED WIRE
SENS GND
SENS SPLY
W/ AMP
W/O AMP
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (3 of 4) -> SENS SPLY
