Kia K5 III (2019-2023) pwr sens sens pwr Wiring diagram
This page shows the only wiring diagram for the component.pwr sens sens pwr, which is found in the car Kia K5 III (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pwr sens sens pwr (1 of 1)
APS 1 PWR
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CYL 1
CYL 3
ECTS 1 GND
ECTS 2 GND
ENGINE COOLANT TEMPERATURE SENSOR 1
ENGINE COOLANT TEMPERATURE SENSOR 2
EWGA GND
EWGA PWR
EWGA SIG
EXH TEMP SENS GND
GRN WIRE
GRY WIRE
GRY/ORG WIRE
INJ CTRL 2
INJ CTRL 3
INSTRUMENT CLUSTER SYSTEM
LOCAL-CAN 1 HI
MOTOR
MOTOR HI
MOTOR SHIELD
ORG/ WIRE
PNK WIRE
PWR SENS SENS PWR
RED WIRE
RPA GND
SENS GND
SENS PWR
SENS SIG
SNDR SIG 2
TMM MOTOR (REAR OF ENGINE)
TPS GND
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l turbo, engine controls circuit (1 of 9) -> PWR SENS SENS PWR
