Kia K5 III (2019-2023) pdw gnd Wiring diagram
This page shows the only wiring diagram for the component.pdw gnd, which is found in the car Kia K5 III (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pdw gnd (1 of 1)
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
BRN WIRE
CENTER CONSOLE SWITCH
COMPUTER DATA LINES SYSTEM
GRN WIRE
IBU
ILL
LEFT PARKING DISTANCE WARNING FORWARD SENSOR
LEFT PARKING DISTANCE WARNING FORWARD SENSOR (CENTER)
LID 1
LID 2
LID 3
LIN PDW
ORG/ WIRE
PDW GND
PDW OFF SW
PDW ON IND
PDW SWITCH
PDW-F PWR
PDW-R PWR
RED WIRE
RIGHT PARKING DISTANCE WARNING FORWARD SENSOR
RIGHT PARKING DISTANCE WARNING FORWARD SENSOR (CENTER)
WHT WIRE
YEL WIRE
Go to component -> Parking assistant circuit (1 of 2) -> PDW GND
