Kia K5 III (2019-2023) engine speed sig output Wiring diagram
This page shows the only wiring diagram for the component.engine speed sig output, which is found in the car Kia K5 III (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine speed sig output (1 of 1)
A/C RELAY CTRL
AIR CONDITIONING SYSTEM
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
CCV CTRL
CKPS SIG
CMPS (EXHAUST) GND
CMPS (INTAKE) GND CKPS GND
COOLING FANS SYSTEM
ECTS 1 GND
ECTS 2 GND
ECTS 2 SIG
ECTS 3 GND
ECTS 3 SIG
ENGINE COOLANT TEMPERATURE SENSOR 1
ENGINE COOLANT TEMPERATURE SENSOR 2
ENGINE COOLANT TEMPERATURE SENSOR 3
ENGINE CTRL RELAY CTRL
ENGINE SPEED SIG OUTPUT
ETC DC MOTOR (-) COOLING FAN PWM OUTPUT
ETC DC MOTOR -
EWGA GND
EXTERNAL WAKE-UP SIG
FUEL PUMP RELAY CTRL
GRN WIRE
GRY WIRE
IAT SIG
IAT, MAP SENSOR (LEFT SIDE OF ENGINE)
MTR
OCV EX CTRL
OIL PRESSURE SENSOR
OIL PRESSURE SIG
OIL PRESSURE/ TEMPERATURE SENSOR
OIL TEMPERATURE SENSOR
ORG/ WIRE
PNK WIRE
RCV CTRL
RED WIRE
SENS GND
SENS SHIELD
SENS SIG
SIG
START RELAY (ISG)
STARTING/CHARGING SYSTEM
TPS GND
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Wiring diagram engine performance 2.5l turbo, engine controls circuit (1 of 7) -> ENGINE SPEED SIG OUTPUT
