Kia K5 III (2019-2023) crush pad switch Wiring diagram
This page shows the only wiring diagram for the component.crush pad switch, which is found in the car Kia K5 III (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram crush pad switch (1 of 1)
A/C CONTROL MODULE
A/C SWITCH
ADAS UNIT
BLK WIRE
BLK/ORG WIRE
CLOCKSPRING
CRUSH PAD SWITCH
DATA LINK CONNECTOR
DOOR LOCK RELAY
DOOR UNLOCK RELAY
ELECTRO- CHROMIC MIRROR
FET (FIELD EFFECT TRANSISTOR)
FRONT MOOD LAMP UNIT
FRONT POWER OUTPUT
FRONT USB CHARGER
GRY WIRE
HAZARD SWITCH
HEAD-UP DISPLAY
IBU
ICU-E
ICU-G
IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH
INSTRUMENT CLUSTER
IPS CONTROL MODULE
LANE KEEPING ASSIST UNIT
LEFT FRONT VANITY LAMP
LEFT REAR PERSONAL LAMP
MULTI- FUNCTION SWITCH
NCA WIRE
OVERHEAD CONSOLE LAMP
RAIN SENSOR
REAR CHILD DOOR LOCK RELAY
REAR CHILD DOOR UNLOCK RELAY
RIGHT FRONT MOOD LAMP
RIGHT FRONT VANITY LAMP
RIGHT REAR PERSONAL LAMP
ROOM LAMP
SPAC: A
SPAC: B/C
STEERING WHEEL HEATED MODULE
STEERING WHEEL)
SUNROOF OVERHEAD CONSOLE LAMP
TRUNK LID SWITCH
TWO TURN UNLOCK RELAY
W/ SUNROOF
W/O SUNROOF
Go to component -> Ground distribution circuit (1 of 6) -> CRUSH PAD SWITCH
