Kia K5 III (2019-2023) acc/on input acc/on output acc/on output Wiring diagram
This page shows the only wiring diagram for the component.acc/on input acc/on output acc/on output, which is found in the car Kia K5 III (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram acc/on input acc/on output acc/on output (1 of 1)
ACC/ON INPUT
ACC/ON INPUT ACC/ON OUTPUT ACC/ON OUTPUT
ACC/ON OUTPUT
ADAS UNIT
AUDIO
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER (AMP) (RIGHT OF HVAC BLOWER)
GRN WIRE
GRY WIRE
HOT W/ ACC RELAY ENERGIZED
HOT W/ LONG TERM LOAD LATCH RELAY ENERGIZED
I-CAN HIGH
I-CAN LOW
ICU JUNCTION BLOCK
ICU-E
ICU-F
ILL (+) M-CAN HIGH
ILL (-) M-CAN LOW
LEFT MIC
LH MIC (+)
LH MIC (-) CAMERA DETECT 2
MEMORY POWER
MIC -
MODULE 4 FUSE
MODULE 8 FUSE
MTS KEYPAD SIG
MULTI MEDIA FUSE
ON/START INPUT
ORG/ WIRE
OVERHEAD CONSOLE LAMP
PNK WIRE
RED WIRE
RELAY ENERGIZED
SOS UVO
SPAC: A
SPAC: B/C
SURROUND VIEW MONITOR UNIT
USB GND
USB HIGH
USB LOW
USB VCC
W/ ISG
W/O ISG
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, w/o navigation & amplifier (3 of 3) -> ACC/ON INPUT ACC/ON OUTPUT ACC/ON OUTPUT
