Kia K5 II (2015-2020) stop lp sw sig low wiring diagram
This page shows the only wiring diagram for the component.stop lp sw sig low, which is found in the car Kia K5 II (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
stop lp sw sig low wiring diagram (1 of 1)
2.0L TURBO
2.4L
B-CAN
BLK WIRE
BLU/ORG WIRE
BRAKE SWITCH 1 FUSE
BRAKE/
BRN WIRE
C-CAN
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
ESC MODULE
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
I/P-C
I/P-D
I/P-E
IND
INSTRUMENT CLUSTER
IPS CONTROL MODULE
LEAK CURRENT AUTO CUT DEVICE
LEFT TURN IND
LIGHT SW
MEMORY 1 FUSE
MICOM
MODULE 3 FUSE
PCM (2.4L, 2.0L TURBO) ECM
PNK WIRE
RED WIRE
REG
RIGHT TURN IND
S GND
SMART JUNCTION BLOCK
SMART KEY CONTROL MODULE
STOP LAMP SWITCH
STOP LP SW SIG LOW
TAIL ON
TEST SW
TRANSCEIVER/
W/ EPB
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Exterior lamps circuit, except hybrid (3 of 3) -> STOP LP SW SIG LOW
