Kia K5 II (2015-2020) ssb ign led Wiring diagram
This page shows the only wiring diagram for the component.ssb ign led, which is found in the car Kia K5 II (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ssb ign led (1 of 1)
2.0L HYBRID, 2.0L PLUG IN HYBRID
2.0L PLUG-IN HYBRID
ACC RLY CTRL
ANT #1 GND
ANT #1 PWR
ANT 2 GND
ANT 2 PWR
BCM
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE SWITCH FUSE
BRN WIRE
BUMPER ANT GND
BUMPER ANT PWR
C-CAN
C-CAN HIGH
C-CAN LOW
CENTER REAR OF LUGGAGE COMPT)
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DRV DR ANT GND
DRV DR ANT PWR
EXTERNAL ANTENNA
EXTERNAL BUZZER
GND 2
GND SIG 2
GRN WIRE
GRN/ORG WIRE
HOT AT ALL TIMES
I/P-D
I/P-E
IGPM
IMMO GND
IMMO IND
IMMO PWR
INSTRUMENT CLUSTER
INTERNAL RECEIVER
KEY ILL
MEMORY POWER CPU
MEMORY POWER LOAD
MICOM
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PASS DR ANT GND
PASS DR ANT PWR
POWER DISTRIBUTION SYSTEM
RED WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
SMART KEY ANTENNA (INTERIOR 1)
SMART KEY ANTENNA (INTERIOR 2)
SMART KEY BUMPER ANTENNA
SMART KEY CONTROL MODULE (RIGHT END OF DASH)
SMART KEY FUSE
SMART KEY TRUNK ANTENNA
SSB ACC LED
SSB IGN LED
TRANSCEIVER/
TRUNK ANT GND
TRUNK ANT PWR
WHT WIRE
WIRELESS CHARGER SIG
YEL WIRE
YEL/ORG WIRE
Go to component -> Immobilizer circuit, hybrid (3 of 3) -> SSB IGN LED
