Kia K5 II (2015-2020) right map lamp Wiring diagrams
This page contains all the electrical diagrams for the component. right map lamp, in which he is found in the car Kia K5 II (2015-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right map lamp (1 of 2)
BLK WIRE
BRN WIRE
C-CAN
CENTER PERSONAL LAMP
CENTER ROOM LAMP
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DOOR
GRY WIRE
HOT IN ON OR START
I/P-D
INSTRUMENT CLUSTER
INSTRUMENT ILLUMINATION CIRCUIT
LEFT FRONT VANITY LAMP
LEFT FRONT VANITY LAMP SWITCH
LEFT MAP LAMP
LEFT REAR PERSONAL LAMP
MICOM
MOOD LAMP
OFF
OVERHEAD CONSOLE LAMP
RED WIRE
REG
RIGHT FRONT VANITY LAMP
RIGHT FRONT VANITY LAMP SWITCH
RIGHT MAP LAMP
RIGHT REAR PERSONAL LAMP
ROOM
S GND
SMART JUNCTION BLOCK
TRANSCEIVER/
W/ ROOM LAMP
W/ SUNROOF
W/ SUNROOF W/O SUNROOF
W/O ROOM LAMP
W/O SUNROOF
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Courtesy lamps circuit, except hybrid (2 of 2) -> RIGHT MAP LAMP
Wiring diagram right map lamp (2 of 2)
BLK WIRE
BRN WIRE
C-CAN
CENTER PERSONAL LAMP
CENTER ROOM LAMP
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DOOR
I/P-D
IGPM
ILL
INSTRUMENT CLUSTER
INSTRUMENT ILLUMINATION CIRCUIT
LEFT FRONT VANITY LAMP
LEFT FRONT VANITY LAMP SWITCH
LEFT MAP LAMP
LEFT REAR PERSONAL LAMP
MICOM
OFF
OVERHEAD CONSOLE LAMP
RED WIRE
REG
RELAY ENERGIZED
RIGHT FRONT VANITY LAMP
RIGHT FRONT VANITY LAMP SWITCH
RIGHT MAP LAMP
RIGHT REAR PERSONAL LAMP
ROOM
SIG 1 GND
TRANSCEIVER/
W/ SUNROOF W/O SUNROOF W/ CENTER ROOM LAMP W/O CENTER ROOM LAMP
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Courtesy lamps circuit, hybrid (2 of 2) -> RIGHT MAP LAMP
