Kia K5 II (2015-2020) memory pwr cpu Wiring diagrams
This page contains all the electrical diagrams for the component. memory pwr cpu, in which he is found in the car Kia K5 II (2015-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram memory pwr cpu (1 of 3)
2.0L HYBRID
2.0L PLUG-IN HYBRID
ABS IND.
AUTO HOLD IND (WHITE/YELLOW/ GREEN)
BCM
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE SWITCH FUSE
BRAKE TEST SW
BRN WIRE
C-CAN TRANSCEIVER
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
ESC IND
ESC OFF IND
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
HPCU
HYBRID POWER CONTROL UNIT
I/P-C
I/P-D
I/P-E
IGPM
INSTRUMENT CLUSTER
MEMORY PWR CPU
MICOM
MODULE 3 FUSE
PARKING BRAKE IND.
PCM
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
S GND 1
SMART KEY CONTROL MODULE
STOP LAMP SIG
STOP LAMP SWITCH
STOP LP SIG
TFT LCD (4.3 INCH) (AUTO HOLD) (SUPERVISION)
VEHICLE SPD
WHT WIRE
YEL/ORG WIRE
Go to component -> Anti-lock brakes circuit, hybrid (3 of 3) -> MEMORY PWR CPU
Wiring diagram memory pwr cpu (2 of 3)
ANT #1 GND
ANT #1 PWR
ANT 2 GND
ANT 2 PWR
AUTO LIGHT, PHOTO SENSOR
B-CAN HIGH
B-CAN LOW
BCM
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE SWITCH FUSE
BRN WIRE
BUMPER ANT PWR
BUMPER GND
C-CAN
CENTER REAR OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
DRV DR ANT GND
DRV DR ANT PWR
EXTERNAL BUZZER
GRN WIRE
GRN/ORG WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
I/P-D
I/P-E
IMMO ANT GROUND
IMMO ANT POWER
IMMO IND
INSTRUMENT CLUSTER
KEY ILL
LEAK CURRENT AUTO CUT DEVICE
MEMORY 1 FUSE
MEMORY POWER LOAD
MEMORY PWR CPU
MICOM
ORG/ WIRE
ORG/BLK WIRE
PASS DR ANT GND
PASS DR ANT PWR
PNK WIRE
RED WIRE
RIGHT END OF DASH)
RLY CTRL ACC
SECURITY IND
SECURITY INDICATOR
SMART JUNCTION BLOCK
SMART KEY ANTENNA (INTERIOR 1)
SMART KEY ANTENNA (INTERIOR 2)
SMART KEY BUMPER ANTENNA
SMART KEY CONTROL MODULE (RIGHT END OF DASH)
SMART KEY FUSE
SMART KEY TRUNK ANTENNA
SSB ACC ILL OUT
SSB IGN ILL OUT
TRANSCEIVER/
TRUNK ANT PWR
TRUNK GND
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Immobilizer circuit, except hybrid w/ smart key system (3 of 3) -> MEMORY PWR CPU
Wiring diagram memory pwr cpu (3 of 3)
2.0L HYBRID
B-CAN HIGH
B-CAN LOW
BCM
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE LIGHT SW
BRAKE SWITCH FUSE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOWN SHIFT
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
HPCU
HYBRID POWER CONTROL UNIT
I/P-A
I/P-C
I/P-E
IGPM
INTEGRATED BRAKE ACTUATION UNIT
IPS CONTROL MODULE
MEMORY PWR CPU
MODULE 3 FUSE
ORG/ WIRE
P POSITION
P POSITION SWITCH
P-CAN HIGH
P-CAN LOW
PCM
RED WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
SELECT SWITCH
SHIFT LOCK SOLENOID
SMART KEY CONTROL MODULE
SPORT MODE SWITCH
STOP LAMP SIG
STOP LAMP SWITCH
TRANSMISSIONS SYSTEM
UP SHIFT
WHT WIRE
YEL WIRE
YEL/ORG WIRE
{\W6.33333; }2.0L PLUG-IN {\W5.881; }HYBRID
Go to component -> Shift interlock circuit, hybrid -> MEMORY PWR CPU
