Kia K5 II (2015-2020) m-can low m-can high Wiring diagram
This page shows the only wiring diagram for the component.m-can low m-can high, which is found in the car Kia K5 II (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram m-can low m-can high (1 of 1)
1.6L TURBO 2.0L TURBO, 2.4L 4.0 VERSION, PIO 1.0 VERSION
4.0 VERSION, 1.0 VERSION
A/C CONTROL MODULE
AMP (RIGHT SIDE OF LUGGAGE COMPT)
AUTOMATIC A/C
B-CAN
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN
C-CAN HIGH
C-CAN LOW
CCP-CAN HIGH
CCP-CAN LOW
DATA LINK CONNECTOR
DBL UNIT
FLEX RAY HIGH
FLEX RAY LOW
GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HOT AT ALL TIMES
I/P-D
I/P-E
INSTRUMENT CLUSTER
IPS CONTROL MODULE
KEYBOARD
LANE KEEPING ASSIST MODULE
LEAK CURRENT AUTO CUT DEVICE
M-CAN HIGH
M-CAN HIGH 29 32 M-CAN LOW
M-CAN LOW
M-CAN LOW M-CAN HIGH
MANUAL A/C
MDPS UNIT (RACK TYPE) (LEFT REAR OF ENGINE ROOM)
MEMORY 1 FUSE
NCA WIRE
ORG/ WIRE
PIO
SMART JUNCTION BLOCK
STEERING ANGLE SENSOR (W/ ESC, W/O MDPS) (TOP OF STEERING COLUMN)
W/ LED W/O LED
W/ LKAS
W/O LKAS
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit, except hybrid (1 of 3) -> M-CAN LOW M-CAN HIGH
