Kia K5 II (2015-2020) cooling fan rly ctrl low pwm fan ctrl Wiring diagram
This page shows the only wiring diagram for the component.cooling fan rly ctrl low pwm fan ctrl, which is found in the car Kia K5 II (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cooling fan rly ctrl low pwm fan ctrl (1 of 1)
2.0L TURBO
2.0L TURBO 1.6L TURBO
2.0L TURBO 2.4L 1.6L TURBO 2.0L TURBO, 1.6L TURBO 2.4L, 2.0L TURBO
2.4L
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
C-CAN HIGH
COMPUTER DATA LINES SYSTEM
CONDITIONING
COOLING FAN 1 FUSE
COOLING FAN 1 RELAY
COOLING FAN 2 FUSE
COOLING FAN 2 RELAY
COOLING FAN MOTOR
COOLING FAN MOTOR (2.4L) (BEHIND RADIATOR)
COOLING FAN RLY CTRL (HIGH)
COOLING FAN RLY CTRL LOW PWM FAN CTRL
E/R JUNCTION BLOCK
E/R-B
E/R-D
ECM (1.6L TURBO) PCM (2.0L TURBO, 2.4L)
ECTS GROUND
ECTS SIGNAL
ENGINE CONTROL RELAY
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE CTRL RLY CTRL C-CAN LOW
HOT AT ALL TIMES
MICOM
NCA WIRE
ORG/ WIRE
PCB BLOCK
POWER
RED WIRE
RED/BLK WIRE
SENSOR 2 FUSE
TEMP
WHT WIRE
Go to component -> Cooling fan circuit, except hybrid -> COOLING FAN RLY CTRL LOW PWM FAN CTRL
