Kia K5 II (2015-2020) bus bar Wiring diagram
This page shows the only wiring diagram for the component.bus bar, which is found in the car Kia K5 II (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bus bar (1 of 1)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BMS ASSEMBLY (MAIN)
BMS CONTROL MODULE (MAIN)
BUS BAR
FUSE
GRN WIRE
GRY WIRE
HV-
MAIN BATTERY MODULE 10
MAIN BATTERY MODULE 7
MAIN BATTERY MODULE 8
MAIN BATTERY MODULE 9
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
TO BATTERY MODULE 11 (DIAGRAM 8 OF 8)
TO POWER RELAY ASSEMBLY (DIAGRAM 3 OF 8) TO BATTERY MODULE 1 (DIAGRAM 5 OF 8)
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.0l plug-in hybrid, hybrid control circuit (7 of 8) -> BUS BAR
