Kia K5 II (2015-2020) b/up lamp fuse Wiring diagrams
This page contains all the electrical diagrams for the component. b/up lamp fuse, in which he is found in the car Kia K5 II (2015-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram b/up lamp fuse (1 of 2)
2.0L TURBO 2.4L A/T DCT
AUDIO
B/UP LAMP FUSE
BACKUP
BACKUP LAMP
BLK WIRE
BLU WIRE
BRN WIRE
E/R-D
E/R-F
ELECTROCHROMIC MIRROR
GRN WIRE
GRY WIRE
HOT IN ON OR START
LEFT REAR COMBINATION LAMP (IN)
N POSITION SW CODE PNK D POSITION SW CODE WIRE
NCA WIRE
ON/START INPUT
P POSITION SW CODE
PCB BLOCK
PCM
PNK WIRE
PNK/BLK WIRE
R POSITION SW CODE PNK ON/START INPUT WIRE
RED WIRE
RIGHT REAR COMBINATION LAMP (IN)
SIG
SIG (1)
SIG (2)
SIG 3
SIG 4
TCM
TCU 2 FUSE
TRANSAXLE RANGE SWITCH
TRANSAXLE RANGE SWITCH (TOP OF TRANSAXLE)
WHT WIRE
Go to component -> Backup lamps circuit, except hybrid -> B/UP LAMP FUSE
Wiring diagram b/up lamp fuse (2 of 2)
2.0L HYBRID
2.0L PLUG-IN HYBRID
AUDIO
B/UP LAMP FUSE
BACKUP
BACKUP LAMP
BLK WIRE
BLU WIRE
BRN WIRE
E/R JUNCTION BLOCK
E/R-D
E/R-F
ELECTROCHROMIC MIRROR
GRN WIRE
LEFT REAR COMBINATION LAMP (IN)
LP SIG
NCA WIRE
PCB BLOCK
PCM
PNK ON/START INPUT WIRE
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT REAR COMBINATION LAMP (IN)
SIG (1)
SIG (2)
SIG 3
SIG 4
TCU 2 FUSE
TRANSAXLE RANGE SWITCH (TOP OF TRANSAXLE)
Go to component -> Backup lamps circuit, hybrid -> B/UP LAMP FUSE
