Kia K5 I facelift (2013-2015) yel Wiring diagrams

This page contains all the electrical diagrams for the component. yel, in which he is found in the car Kia K5 I facelift (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

yel wiring diagram (1 of 172)

BLK WIRE BLK/RED WIRE BLOWER BLOWER (+) ON/START INPUT BLU WIRE BRN WIRE DRIVER CCS BLOWER MOTOR DRIVER CCS CONTROL MODULE DRIVER CCS CUSHION WARMER DRIVER COOL SWITCH DRIVER HEATER SWITCH FRONT SEAT WARMER, CCS SWITCH GRN WIRE GRN/ORG WIRE GRY WIRE HIGH IND HOT AT ALL TIMES HOT IN ON OR START I/P-A I/P-F LOW HIGH LOW IND LT GRN WIRE MODULE 4 FUSE NCA WIRE NTC (+) HIGH IND NTC (-) LOW IND NTC + GND NTC- ORG/ WIRE PASSENGER CCS BLOWER MOTOR PASSENGER CCS CONTROL MODULE PASSENGER CCS CUSHION WARMER PASSENGER COOL SWITCH PASSENGER HEATER SWITCH PNK WIRE POWER RED WIRE RED/BLU WIRE S/HEATER (FRT)/ SEAT VENT (FRT) FUSE SMART JUNCTION BOX SPEED CONTROL SW SIG SWITCH SWITCH LOW WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/ORG WIRE

Go to component -> Climate control seats circuit -> YEL WIRE

yel wiring diagram (2 of 172)

AUTO HEADLAMP LEVELING DEVICE B-CAN HIGH B-CAN K- HIGH LOW LINE B-CAN LOW BCM BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/BLK WIRE C-CAN C-CAN HIGH C-CAN LOW DATA LINK CONNECTOR DRIVER IMS MODULE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES I/P-F I/P-G INSTRUMENT CLUSTER IPS CONTROL MODULE B-CAN LINE LOW HIGH JOINT CONNECTOR UMC K- SPD LINE SIG LEAK CURRENT AUTO CUT DEVICE LOW HIGH MEMORY 1 FUSE MODULE ORG/ WIRE PANORAMA SUNROOF POWER DISTRIBUTION SYSTEM RED WIRE RED/WHT WIRE SMART JUNCTION BOX SPD HIGH LOW SIG C-CAN TELEMATICS UNIT WHT WIRE WHT/ORG WIRE YEL WIRE YEL/ORG WIRE

Go to component -> Computer data lines circuit, except hybrid (1 of 3) -> YEL WIRE

yel wiring diagram (3 of 172)

A/C CONTROL MODULE AMP AUTOMATIC A/C MANUAL A/C B-CAN HIGH B-CAN LOW BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE C-CAN C-CAN HIGH C-CAN K- LOW HIGH HIGH LINE C-CAN LOW ELECTRIC PARKING BRAKE MODULE GRY WIRE GRY/BLK WIRE HIGH LOW LOW HIGH M-CAN PASSENGER WEIGHT CLASSIFICATION SENSOR RIGHT END OF DASH) SMART KEY CONTROL MODULE TIRE PRESSURE MONITORING MODULE W/ EPB WHT WIRE WHT/ORG WIRE YEL WIRE YEL/ORG WIRE

Go to component -> Computer data lines circuit, except hybrid (2 of 3) -> YEL WIRE

yel wiring diagram (4 of 172)

10-WAY 2 WAY BLK WIRE BLK/GRN WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BWD BWD FWD DRIVER FRONT HEIGHT ADJUSTER MOTOR DRIVER FRONT HEIGHT ADJUSTER SWITCH DRIVER LUMBAR SUPPORT MOTOR DRIVER LUMBAR SUPPORT SWITCH DRIVER REAR HEIGHT ADJUSTER MOTOR DRIVER REAR HEIGHT ADJUSTER SWITCH DRIVER RECLINING LIMIT SWITCH DRIVER RECLINING MOTOR DRIVER RECLINING SWITCH DRIVER SEAT MANUAL SWITCH DRIVER SLIDE SWITCH DRIVER'S SLIDE MOTOR GRN WIRE GRY WIRE HOT AT ALL TIMES I/P-A P/SEAT (DRV) FUSE RED WIRE SMART JUNCTION BOX WHT WIRE YEL WIRE

Go to component -> Driver power seat circuit -> YEL WIRE

yel wiring diagram (5 of 172)

BLK WIRE C-CAN TRANSCEIVER CLUSTER FUSE COMPUTER DATA LINES SYSTEM E/R FUSE, RELAY BOX EPS IND HOT AT ALL TIMES HOT IN ON OR START I/P-E INSTRUMENT CLUSTER J/C UMC MDPS FUSE MDPS UNIT MEMORY PWR MICOM MULTI FUSE PNK ON/START IN WIRE PNK WIRE RED WIRE SMART JUNCTION BOX WHT WIRE YEL WIRE

Go to component -> Electronic power steering circuit -> YEL WIRE

yel wiring diagram (6 of 172)

BLK WIRE BLK/BLU WIRE BLU WIRE BRN WIRE DRIVER SEAT SWITCH DRIVER'S CUSHION WARMER DRIVER'S SEAT WARMER MODULE FRONT SEAT WARMER, CCS SWITCH GRN WIRE GRN/WHT WIRE GRY WIRE HIGH IND HOT AT ALL TIMES HOT IN ON OR START HTD (+) HTD SW SIG HTD (-) GND HTD(-) I/P-A I/P-F LOW HIGH LOW IND MEMORY POWER MODULE 4 FUSE NCA WIRE NTC- ON/START INPUT PASSENGER CUSHION WARMER PASSENGER SEAT SWITCH PASSENGER SEAT WARMER MODULE PNK WIRE RED WIRE RED/ORG WIRE RED/YEL WIRE S/HEATER (FRT)/ SEAT VENT (FRT) FUSE SMART JUNCTION BOX SWITCH SWITCH LOW WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE

Go to component -> Front heated seats circuit -> YEL WIRE

yel wiring diagram (7 of 172)

BLK WIRE BLU WIRE CLOCK- SPRING CRASH PAD SWITCH GRN WIRE HEATER PAD HOT IN ON HTD STRG FUSE I/P-E IND INSTRUMENT CLUSTER JOINT CONNECTOR UMC NTC + GND ON INPUT GND POWER GND RED WIRE SMART JUNCTION BOX STEERING WHEEL HEATER MODULE STEERING WHEEL HEATER SWITCH STEERING WHEEL) SWITCH WHT WIRE YEL WIRE

Go to component -> Heated steering wheel circuit -> YEL WIRE

yel wiring diagram (8 of 172)

BLK WIRE BLU WIRE BWD FWD BWD GRN WIRE GRY WIRE HOT AT ALL TIMES I/P-A P/SEAT PASS FUSE PASSENGER RECLINING MOTOR PASSENGER RECLINING SWITCH PASSENGER SEAT MANUAL SWITCH PASSENGER SLIDE MOTOR PASSENGER SLIDE SWITCH PASSENGER'S RECLINING LIMIT SWITCH RED WIRE SMART JUNCTION BOX WHT WIRE YEL WIRE

Go to component -> Passenger power seat circuit -> YEL WIRE

yel wiring diagram (9 of 172)

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE GRY WIRE GRY/ORG WIRE HIGH IND HOT AT ALL TIMES HOT IN ON HOT IN ON OR START HTD(-) I/P-A I/P-E ILL LEFT "C" PILLAR) LEFT REAR POWER WINDOW SWITCH LEFT REAR SEAT WARMER LEFT REAR SEAT WARMER MODULE LEFT REAR SEAT WARMER SWITCH LOW IND MEMORY PWR MODULE 4 FUSE MODULE 6 FUSE MODULE 7 FUSE NCA WIRE NTC- ON INPUT ON/START INPUT PNK WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT REAR POWER WINDOW SWITCH RIGHT REAR SEAT WARMER RIGHT REAR SEAT WARMER MODULE RIGHT REAR SEAT WARMER SWITCH S/HEATER RR FUSE SMART JUNCTION BOX SW SIG YEL WIRE YEL/ORG WIRE YEL/RED WIRE

Go to component -> Rear heated seats circuit, except hybrid -> YEL WIRE

yel wiring diagram (10 of 172)

BLK WIRE BLU WIRE BLU/RED WIRE GRY WIRE GRY/ORG WIRE HIGH IND HOT AT ALL TIMES HOT IN ON HOT IN ON OR START I/P-A I/P-E ILL LEFT "C" PILLAR) LEFT REAR POWER WINDOW SWITCH LEFT REAR SEAT WARMER LEFT REAR SEAT WARMER SWITCH LOW IND MEMORY PWR MODULE 4 FUSE MODULE 6 FUSE MODULE 7 FUSE ON INPUT ON/START INPUT RED/BLK WIRE RED/WHT WIRE RIGHT REAR POWER WINDOW SWITCH RIGHT REAR SEAT WARMER RIGHT REAR SEAT WARMER SWITCH S/HEATER RR FUSE SMART JUNCTION BOX SW SIG YEL WIRE

Go to component -> Rear heated seats circuit, hybrid -> YEL WIRE
