Kia K5 I facelift (2013-2015) start feedback Wiring diagram
This page shows the only wiring diagram for the component.start feedback, which is found in the car Kia K5 I facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram start feedback (1 of 1)
BATTERY POWER
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE LT SW
BRAKE SW
C-CAN (H)
C-CAN (L)
CLUTCH PRESS SNSR (GND)
CLUTCH PRESS SNSR (PWR)
CLUTCH PRESS SNSR (SIG)
CLUTCH PRESSURE SENSOR
COMPUTER DATA LINES SYSTEM
E/R FUSE, RELAY BOX
FOB HOLDER
FOB-IN
GRN WIRE
GRN/ORG WIRE
GRY WIRE
H-CAN (H)
H-CAN (L)
HEV ECU FUSE
HOT AT ALL TIMES
HOT IN ON OR START
HYBRID CONTROL UNIT
HYBRID POWER CONTROL UNIT
I/P-D
I/P-E
I/P-F
ON/START INPUT
PDM 2 FUSE
PNK WIRE
PWM
RED WIRE
RIGHT END OF DASH)
SIG
SMART JUNCTION BOX
SMART KEY CONTROL MODULE
START FEEDBACK
START FUSE
START SIG
START STOP BUTTON SWITCH
TRANSAXLE RANGE SWITCH
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/ORG WIRE
Go to component: -> Wiring diagram engine performance 2.4l hybrid, hybrid control circuit (6 of 6) -> START FEEDBACK
