Kia K5 I facelift (2013-2015) right rear power window motor Wiring diagrams

This page contains all the electrical diagrams for the component. right rear power window motor, in which he is found in the car Kia K5 I facelift (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram right rear power window motor (1 of 2)

Wiring diagram right rear power window motor for Kia K5 I facelift (2013-2015)

Get access

AUTO DOWN AUTO UP UP BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE DK GRN WIRE DOOR LOCK SWITCH DOOR LOCKS SYSTEM DOWN DRIVER WINDOW SWITCH GRN WIRE GRY WIRE HOT AT ALL TIMES I/P-A ILL IPS CONTROL MODULE LEFT P/WDW RELAY LEFT REAR POWER WINDOW MOTOR LEFT REAR WINDOW SWITCH LH PWR WINDOW RELAY CONTROL OFF ORG/ WIRE P/WDW LH FUSE P/WDW RH FUSE PASSENGER WINDOW SWITCH PNK WIRE PNK/BLK WIRE POWER WINDOW MAIN SWITCH RED WIRE RH PWR WINDOW RELAY CONTROL RIGHT P/WDW RELAY RIGHT REAR POWER WINDOW MOTOR RIGHT REAR WINDOW SWITCH SMART JUNCTION BOX WHT WIRE WINDOW LOCK SWITCH YEL WIRE YEL/BLK WIRE

Go to component: -> Power windows circuit, w/ auto up/down power window (1 of 2) -> RIGHT REAR POWER WINDOW MOTOR

Wiring diagram right rear power window motor (2 of 2)

Wiring diagram right rear power window motor for Kia K5 I facelift (2013-2015)

Get access

AUTO DOWN BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRN WIRE CONTROL UNIT) DOOR LOCK SWITCH DOOR LOCKS SYSTEM DOWN DRIVER POWER WINDOW MOTOR DRIVER WINDOW SWITCH GRN WIRE GRY WIRE HOT AT ALL TIMES I/P-A ILL IPS CONTROL MODULE JOINT CONNECTOR UDA LEFT P/WDW RELAY LEFT REAR POWER WINDOW MOTOR LEFT REAR WINDOW SWITCH LH PWR WINDOW RELAY CONTROL OFF ORG/ WIRE P/WDW LH FUSE P/WDW RH FUSE PASSENGER WINDOW SWITCH PNK WIRE PNK/BLK WIRE POWER WINDOW MAIN SWITCH RED WIRE RH PWR WINDOW RELAY CONTROL RIGHT P/WDW RELAY RIGHT REAR POWER WINDOW MOTOR RIGHT REAR WINDOW SWITCH SMART JUNCTION BOX WHT WIRE WINDOW LOCK SWITCH YEL WIRE YEL/BLK WIRE

Go to component: -> Power windows circuit, w/o auto up/down power window (1 of 2) -> RIGHT REAR POWER WINDOW MOTOR
