Kia K5 I facelift (2013-2015) remote ctrl sw gnd pnk usb d- Wiring diagrams

This page contains all the electrical diagrams for the component. remote ctrl sw gnd pnk usb d-, in which he is found in the car Kia K5 I facelift (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram remote ctrl sw gnd pnk usb d- (1 of 2)

Wiring diagram remote ctrl sw gnd pnk usb d- for Kia K5 I facelift (2013-2015)

Get access

AUDIO AUX DET AUX DETECT AUX GND AUX L + AUX L IN AUX R + AUX R IN AUX, USB JACK BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRN WIRE CIRCUIT CRUISE CONTROL SYSTEM F/CABLE FL (-) FR (-) GLASS ANTENNA MODULE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR ACC I/P-E I/P-F ILL ILL (+) DETENT ILL(-) ANTENNA LEAK CURRENT AUTOCUT DEVICE MEMORY PWR MIC (+) ACC/ON IN MIC - MODULE 1 FUSE MULTI MEDIA FUSE NCA WIRE ORG/ WIRE PNK RL (+) WIRE PNK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM RADIO RED WIRE REMOTE CTRL SW GND PNK USB D- WIRE REMOTE CTRL SW SIG RL (+) ROOF ANTENNA RR (-) SIRIUS SMART JUNCTION BOX USB D- USB GND USB VOD USB/IPOD GND USB/IPOD VOD VEHICLE SPD WHT WIRE YEL WIRE YEL/ORG WIRE

Go to component: -> Radio circuit, w/o navigation w/o uvo & amplifier (1 of 2) -> REMOTE CTRL SW GND PNK USB D- WIRE

Wiring diagram remote ctrl sw gnd pnk usb d- (2 of 2)

Wiring diagram remote ctrl sw gnd pnk usb d- for Kia K5 I facelift (2013-2015)

Get access

AUDIO AUX DET AUX DETECT AUX GND AUX L + AUX L IN AUX R + AUX R IN AUX, USB JACK BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE BRN/BLK WIRE CIRCUIT COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM F/CABLE GLASS ANTENNA MODULE GRN WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES I/P-F ILL ILL (+) DETENT ILL(-) ANTENNA LEAK CURRENT AUTOCUT DEVICE M-CAN HIGH M-CAN LOW MEMORY PWR MIC (+) ACC/ON IN MIC - MULTI MEDIA FUSE NCA WIRE PNK WIRE PNK/BLK WIRE RADIO RED WIRE REMOTE CTRL SW GND PNK USB D- WIRE REMOTE CTRL SW SIG ROOF ANTENNA SIRIUS SMART JUNCTION BOX SPDIF GND SPDIF OUT (-) USB D- USB GND USB VOD USB/IPOD GND USB/IPOD VOD VEHICLE SPD YEL WIRE

Go to component: -> Radio circuit, w/o navigation w/o uvo w/ amplifier (1 of 3) -> REMOTE CTRL SW GND PNK USB D- WIRE
