Kia K5 I facelift (2013-2015) passenger reclining switch Wiring diagram

This page shows the only wiring diagram for the component.passenger reclining switch, which is found in the car Kia K5 I facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram passenger reclining switch (1 of 1)

Wiring diagram passenger reclining switch for Kia K5 I facelift (2013-2015)

Get access

BLK WIRE BLU WIRE BWD FWD BWD GRN WIRE GRY WIRE HOT AT ALL TIMES I/P-A P/SEAT PASS FUSE PASSENGER RECLINING MOTOR PASSENGER RECLINING SWITCH PASSENGER SEAT MANUAL SWITCH PASSENGER SLIDE MOTOR PASSENGER SLIDE SWITCH PASSENGER'S RECLINING LIMIT SWITCH RED WIRE SMART JUNCTION BOX WHT WIRE YEL WIRE

Go to component: -> Passenger power seat circuit -> PASSENGER RECLINING SWITCH
