Kia K5 I facelift (2013-2015) leak current auto cut device Wiring diagrams
This page contains all the electrical diagrams for the component. leak current auto cut device, in which he is found in the car Kia K5 I facelift (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
leak current auto cut device wiring diagram (1 of 2)
AUTO HEADLAMP LEVELING DEVICE
B-CAN HIGH
B-CAN K- HIGH LOW LINE
B-CAN LOW
BCM
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
C-CAN
C-CAN HIGH
C-CAN LOW
DATA LINK CONNECTOR
DRIVER IMS MODULE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
I/P-F
I/P-G
INSTRUMENT CLUSTER
IPS CONTROL MODULE B-CAN LINE LOW HIGH
JOINT CONNECTOR UMC
K- SPD LINE SIG
LEAK CURRENT AUTO CUT DEVICE
LOW HIGH
MEMORY 1 FUSE
MODULE
ORG/ WIRE
PANORAMA SUNROOF
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/WHT WIRE
SMART JUNCTION BOX
SPD HIGH LOW SIG C-CAN
TELEMATICS UNIT
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Computer data lines circuit, except hybrid (1 of 3) -> LEAK CURRENT AUTO CUT DEVICE
leak current auto cut device wiring diagram (2 of 2)
AUTO HEADLAMP LEVELING DEVICE MODULE
B-CAN HIGH
B-CAN K- HIGH LOW LINE
B-CAN LOW
BCM
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
C-CAN
DATA LINK CONNECTOR
DRIVER IMS MODULE
GRY WIRE
GRY/BLK WIRE
HIGH LOW
HOT AT ALL TIMES
I/P-F
I/P-G
INSTRUMENT CLUSTER
IPS CONTROL MODULE B-CAN K- LINE LOW HIGH
JOINT CONNECTOR UMC
K LINE
LEAK CURRENT AUTO CUT DEVICE
LOW HIGH
MEMORY 1 FUSE
MTS MODULE
ORG/ WIRE
PANORAMA SUNROOF
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/WHT WIRE
SMART JUNCTION BOX
SPD SIG
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Computer data lines circuit, hybrid (1 of 4) -> LEAK CURRENT AUTO CUT DEVICE
