Kia K5 I facelift (2013-2015) h-can high 12 11 c-can low Wiring diagram

This page shows the only wiring diagram for the component.h-can high 12 11 c-can low, which is found in the car Kia K5 I facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram h-can high 12 11 c-can low (1 of 1)

Wiring diagram h-can high 12 11 c-can low for Kia K5 I facelift (2013-2015)

Get access

ACTIVE AIR FLAP BLU WIRE C-CAN C-CAN HIGH C-CAN LOW ELECTRIC OIL PUMP H CAN+ H-CAN HIGH 12 11 C-CAN LOW H-CAN LOW HYBRID CONTROL MODULE HYBRID WATER PUMP INTEGRATED BRAKE ACTUATION UNIT LOW HIGH LOW VOLTAGE DC-DC CONVERTER MCU PCM HIGH VESS UNIT WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLU WIRE

Go to component: -> Computer data lines circuit, hybrid (4 of 4) -> H-CAN HIGH 12 11 C-CAN LOW
