Kia K5 I facelift (2013-2015) driver pressure side impact sensor Wiring diagram
This page shows the only wiring diagram for the component.driver pressure side impact sensor, which is found in the car Kia K5 I facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver pressure side impact sensor (1 of 1)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
DRIVER ANCHOR PRETENSIONER
DRIVER CURTAIN AIR BAG
DRIVER PRESSURE SIDE IMPACT SENSOR
DRIVER SEAT BELT BUCKLE SWITCH
DRIVER SEAT BELT PRETENSIONER
DRIVER SEAT TRACK POSITION SENSOR
DRIVER SIDE AIR BAG
DRIVER SIDE IMPACT SENSOR
DRIVER'S DOOR
GRN WIRE
GRN/BLK WIRE
GRY WIRE
ORG/ WIRE
ORG/BLK WIRE
PASSENGER ANCHOR PRETENSIONER
PASSENGER CURTAIN AIR BAG
PASSENGER PRESSURE SIDE IMPACT SENSOR
PASSENGER SEAT BELT BUCKLE SWITCH
PASSENGER SEAT BELT PRETENSIONER
PASSENGER SIDE AIR BAG
PASSENGER SIDE IMPACT SENSOR
PNK HIGH WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
SRS CONTROL MODULE (FRONT OF CENTER CONSOLE)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component: -> Supplemental restraints circuit (2 of 2) -> DRIVER PRESSURE SIDE IMPACT SENSOR
