Kia K5 I facelift (2013-2015) door sw Wiring diagrams
This page contains all the electrical diagrams for the component. door sw, in which he is found in the car Kia K5 I facelift (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram door sw (1 of 2)
2.0L TURBO
2.4L
B-CAN
BLK WIRE
BLU WIRE
BRN WIRE
CGINJ
CLOCK- SPRING
COMPUTER DATA LINES SYSTEM
CRUISE
CRUISE ON/OFF
CRUISE OUT
DES
DOOR SW
GRN WIRE
GRY WIRE
HOT IN ACC OR ON
I/P-B
I/P-E
I/P-G
ILL
IPS CONTROL MODULE
MODULE 1 FUSE
OIL PRESSURE SWITCH
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT CRUISE REMOTE CONTROL SWITCH
RIGHT TRIP ECO REMOTE CONTROL SWITCH
SELECT
SET- RES+
SMART JUNCTION BOX
STEERING WHEEL)
TRIP
TRIP OUT
W/ STEERING WHEEL HEATER W/O STEERING WHEEL HEATER
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Instrument cluster circuit, except hybrid korean made (2 of 4) -> DOOR SW
