Kia K5 I facelift (2013-2015) a/v tail pnk "p" position Wiring diagrams

This page contains all the electrical diagrams for the component. a/v tail pnk "p" position, in which he is found in the car Kia K5 I facelift (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram a/v tail pnk "p" position (1 of 4)

Wiring diagram a/v tail pnk "p" position for Kia K5 I facelift (2013-2015) (1 of 4)

Get access

A/V TAIL PNK "P" POSITION WIRE A/V, NAVIGATION HEAD UNIT AUX DET AUX GND AUX L + AUX R + AUX, USB JACK BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/BLK WIRE CAMERA B+ CAMERA P GND CAMERA V/GND CAMERA V/IN COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DET GRN WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN ON OR START I/P-F ILL ILL (+) BACKUP LP SIG L IN LEAK CURRENT AUTOCUT DEVICE M-CAN HIGH M-CAN LOW MEMORY PWR MIC (+) ACC/ON IN MIC GND MODULE 4 FUSE MULTI MEDIA FUSE NAVI VOICE (+) NCA WIRE ON/START IN ORG/ WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM R IN RED WIRE REMOTE CTRL SW GND REMOTE CTRL SW SIG SMART JUNCTION BOX SPDIF GND SPDIF OUT (-) SPDIF OUT (-) DR UNLK TRANSMISSIONS SYSTEM USB D (-) USB VCC USB D- USB GND USB VCC VEHICLE SPD WHT WIRE YEL WIRE

Go to component -> Navigation circuit, version 3.0 w/ amplifier (1 of 4) -> A/V TAIL PNK "P" POSITION WIRE

Wiring diagram a/v tail pnk "p" position (2 of 4)

Wiring diagram a/v tail pnk "p" position for Kia K5 I facelift (2013-2015) (2 of 4)

Get access

A/V TAIL PNK "P" POSITION WIRE A/V, NAVIGATION HEAD UNIT AM/FM AM/FM AM/FM B+ OUT AM/FM F/CABLE AUX DET AUX GND AUX L + AUX R + AUX, USB JACK B+ BPF BCM TX STATE UNLK BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BPF BRN WIRE BRN/BLK WIRE CAMERA B+ CAMERA V/IN CIRCUIT COMBI ANTENNA MODULE COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DET DR UNLK FL (-) FR (-) GLASS ANTENNA MODULE GPS GPS F/CABLE GPS OUT/B+ GRN WIRE GRY WIRE GRY/BLK WIRE ILL ILL (+) BACKUP LP SIG ILL(-) ANTENNA L IN LNA M-CAN HIGH M-CAN LOW MATCHING CIRCUIT MEMORY PWR MIC (+) ACC/ON IN MIC GND NCA WIRE ON/START IN ORG/ WIRE PNK RL (+) WIRE PNK WIRE PNK/BLK WIRE R IN RED WIRE REMOTE CTRL SW GND REMOTE CTRL SW SIG RFC RFC MATCHING CIRCUIT RL (+) RR (+) CAMERA P GND RR (-) CAMERA V/GND SIRIUS SIRUS SIRUS OUT/B+ TAIL AV TRANSMISSIONS SYSTEM USB D (-) USB VCC USB D- USB GND USB VCC VEHICLE SPD WHT WIRE XM OUT/B+ XMS/SIRUS F/CABLE YEL WIRE YEL/ORG WIRE

Go to component -> Navigation circuit, version 3.0 w/o amplifier (1 of 3) -> A/V TAIL PNK "P" POSITION WIRE
