Kia K5 I facelift (2013-2015) alarm rly ctrl Wiring diagrams

This page contains all the electrical diagrams for the component. alarm rly ctrl, in which he is found in the car Kia K5 I facelift (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram alarm rly ctrl (1 of 2)

Wiring diagram alarm rly ctrl for Kia K5 I facelift (2013-2015)

Get access

ALARM RLY CTRL BLK WIRE BLU WIRE BRN WIRE BRN/ORG WIRE BURGLAR/ DRIVER DOOR LOCK ACTUATOR (REAR OF DRIVER FRONT DOOR) DRV DR DRV DR KEY DRV/PASS DR GRN WIRE GRY WIRE HOOD SWITCH HYBRID EXCEPT HYBRID I/P-B I/P-D I/P-G IPS CONTROL MODULE JOINT CONNECTOR UDA JOINT CONNECTOR UDB JOINT CONNECTOR UDC JOINT CONNECTOR UDD KEY LK SIG KEY LOCK KEY UN LOCK LEFT REAR DOOR LOCK ACTUATOR LK/UNLK SIG LOCK NCA WIRE ORG/ WIRE PASS DR PASS DR KEY PASSENGER DOOR LOCK ACTUATOR (REAR OF PASSENGER FRONT DOOR) PNK WIRE RED WIRE RIGHT REAR DOOR LOCK ACTUATOR RR DR LH RR DR RH STARTING/ CHARGING SYSTEM UN LOCK UN- LOCK LOCK UNLK SIG WHT WIRE YEL WIRE

Go to component: -> Forced entry circuit (2 of 2) -> ALARM RLY CTRL
