Kia K3 II facelift (2021-2024) wiper sw sig Wiring diagram

This page shows the only wiring diagram for the component.wiper sw sig, which is found in the car Kia K3 II facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram wiper sw sig (1 of 1)

Wiring diagram wiper sw sig for Kia K3 II facelift (2021-2024)

Get access

2.0L BLK WIRE BRN WIRE E/R-C E/R-D FRONT WASHER MOTOR SW POWER FRONT WASHER SWITCH FRONT WIPER (LOW) RELAY FRONT WIPER HIGH RELAY FRONT WIPER LOW BACKUP SIG FRONT WIPER MOTOR GND (BCM) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON ICU JUNCTION BLOCK ICU-E INT/VOL SW SIG MIST MULTI- FUNCTION SWITCH ON INPUT ORG/ WIRE PARKING SWITCH PCB BLOCK RED WIRE VOL 1 (FAST) VOL 2 VOL 3 VOL 4 VOL 5 (SLOW) WASHER FUSE WHT WIRE WIPER FUSE WIPER LOW SWITCH WIPER RELAY WIPER SW SIG YEL WIRE

Go to component: -> Wiper/washer circuit (2 of 2) -> WIPER SW SIG
