Kia K3 II facelift (2021-2024) turn sig lamp sw out Wiring diagrams
This page contains all the electrical diagrams for the component. turn sig lamp sw out, in which he is found in the car Kia K3 II facelift (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
turn sig lamp sw out wiring diagram (1 of 2)
2.0L
AUTO
BLK WIRE
BLU WIRE
BRN WIRE
GND (BCM)
GRN WIRE
GRY WIRE
HAZARD SWITCH
HEAD TAIL
HIGH MOUNTED STOP LAMP
IND
LEFT HEADLAMP
LEFT TURN SWITCH
LH TURN LAMP ACT
LH TURN LAMP TELLTALE
LIGHT SW OUT
MULTI- FUNCTION SWITCH
NCA WIRE
OFF
PNK WIRE
POSITION LAMP
RED WIRE
RED/ORG WIRE
RH TURN LAMP ACT
RH TURN LAMP TELLTALE
RIGHT HEADLAMP
RIGHT TURN SWITCH
SIDE MARKER LAMP
TURN LAMP
TURN SIG LAMP SW OUT
W/ LED
W/O LED
WHT WIRE
Go to component -> 1.6l turbo, exterior lamps circuit (3 of 4) -> TURN SIG LAMP SW OUT
turn sig lamp sw out wiring diagram (2 of 2)
2.0L
AUTO
BLK WIRE
BLU WIRE
BRN WIRE
GND (BCM)
GRN WIRE
GRY WIRE
HAZARD SWITCH
HEAD TAIL
HIGH MOUNTED STOP LAMP
IND
LEFT HEADLAMP
LEFT TURN SWITCH
LH TURN LAMP ACT
LH TURN LAMP TELLTALE
LIGHT SW OUT
MULTI- FUNCTION SWITCH
NCA WIRE
OFF
PNK WIRE
POSITION LAMP
RED WIRE
RED/ORG WIRE
RH TURN LAMP ACT
RH TURN LAMP TELLTALE
RIGHT HEADLAMP
RIGHT TURN SWITCH
SIDE MARKER LAMP
TURN LAMP
TURN SIG LAMP SW OUT
W/ LED
W/O LED
WHT WIRE
Go to component -> 2.0l, exterior lamps circuit (3 of 4) -> TURN SIG LAMP SW OUT
