Kia K3 II facelift (2021-2024) rcv control solenoid valve Wiring diagrams

This page contains all the electrical diagrams for the component. rcv control solenoid valve, in which he is found in the car Kia K3 II facelift (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram rcv control solenoid valve (1 of 2)

Wiring diagram rcv control solenoid valve for Kia K3 II facelift (2021-2024)

Get access

CANISTER CLOSE VALVE COOLING FAN 1 RELAY E/R JUNCTION BLOCK E/R JUNCTION BLOCK (LEFT REAR OF ENGINE COMPT) E/R-A E/R-B E/R-D ECU 1 FUSE ECU 2 FUSE ECU 3 FUSE ECU 4 FUSE ENGINE CONTROL RELAY FROM MULTI-FUSE 2 (DIAGRAM 1 OF 10) FUEL PUMP RELAY GRN WIRE GRY WIRE HORN FUSE HORN RELAY IGN COIL FUSE IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 INJECTOR 1 INJECTOR 2 INJECTOR 3 INJECTOR 4 INJECTOR FUSE OIL CONTROL VALVE 1 OIL CONTROL VALVE 2 ORG/ WIRE OXYGEN SENSOR (DOWN) OXYGEN SENSOR (UP) PURGE CONTROL SOLENOID VALVE RCV CONTROL SOLENOID VALVE RED WIRE SENSOR 1 FUSE SENSOR 2 FUSE SENSOR 3 FUSE WHT WIRE WIPER FUSE WIPER RELAY

Go to component: -> 1.6l turbo, power distribution circuit (10 of 10) -> RCV CONTROL SOLENOID VALVE

Wiring diagram rcv control solenoid valve (2 of 2)

Wiring diagram rcv control solenoid valve for Kia K3 II facelift (2021-2024)

Get access

B+5 FUSE BLK WIRE BLU WIRE BLU/ORG WIRE BRAKE BOOSTER VACUUM PRESSURE SENSOR BRN WIRE CANISTER CLOSE VALVE COMPUTER DATA LINES SYSTEM E/R JUNCTION BLOCK E/R-A FUEL PUMP FUSE FUEL PUMP RELAY GRN WIRE GRN/ORG WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START LEFT FRONT STRUT TOWER) MEMORY B+ MULTI FUSE 2 ON/START ORG/ WIRE P-CAN HIGH P-CAN LOW PCB BLOCK PNK WIRE RCV CONTROL SOLENOID VALVE RED WIRE SENSOR 4 FUSE SIGNAL VACUUM PUMP VACUUM PUMP FUSE W/ SMART KEY/IMMO W/O SMART KEY/IMMO WHT WIRE YEL WIRE

Go to component: -> Wiring diagram engine performance 1.6l turbo (5 of 6) -> RCV CONTROL SOLENOID VALVE
