Kia K3 II facelift (2021-2024) passenger power window motor Wiring diagrams

This page contains all the electrical diagrams for the component. passenger power window motor, in which he is found in the car Kia K3 II facelift (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram passenger power window motor (1 of 2)

Wiring diagram passenger power window motor for Kia K3 II facelift (2021-2024)

Get access

BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/BLK WIRE DOOR LOCK SWITCH DOOR LOCKS SYSTEM DOWN GRN WIRE GRY WIRE HIGH IND ILL LEFT REAR POWER WINDOW MOTOR LEFT REAR POWER WINDOW SWITCH LOW IND OFF OFF DOWN ORG/ WIRE PASSENGER POWER WINDOW MOTOR PASSENGER POWER WINDOW SWITCH PNK WIRE RIGHT REAR POWER WINDOW MOTOR RIGHT REAR POWER WINDOW SWITCH SEATS SYSTEM UP OFF W/ REAR SEAT WARMER W/O REAR SEAT WARMER W/O REAR SEAT WARMER W/ REAR SEAT WARMER WHT WIRE YEL WIRE

Go to component: -> Power windows circuit, w/ driver auto down power window (2 of 2) -> PASSENGER POWER WINDOW MOTOR

Wiring diagram passenger power window motor (2 of 2)

Wiring diagram passenger power window motor for Kia K3 II facelift (2021-2024)

Get access

BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/BLK WIRE DIRECTION DOOR LOCK SWITCH DOOR LOCKS SYSTEM DOWN DRIVER SAFETY POWER WINDOW MODULE ENABLE GRN WIRE GRY WIRE HIGH IND IBU ILL LEFT REAR POWER WINDOW MOTOR LEFT REAR POWER WINDOW SWITCH LIN LOW IND OFF OFF DOWN ORG/ WIRE PASSENGER POWER WINDOW MOTOR PASSENGER POWER WINDOW SWITCH PNK WIRE PULSE RED WIRE RIGHT END OF DASH) RIGHT REAR POWER WINDOW MOTOR RIGHT REAR POWER WINDOW SWITCH SAFETY WINDOW ECU SEATS SYSTEM UP OFF VCC W/ REAR SEAT WARMER W/O REAR SEAT WARMER W/O REAR SEAT WARMER W/ REAR SEAT WARMER WHT WIRE YEL WIRE

Go to component: -> Power windows circuit, w/ driver auto up/down & safety power windows (2 of 2) -> PASSENGER POWER WINDOW MOTOR
