Kia K3 II facelift (2021-2024) exterior lights, defogger systems wiring diagram
This page shows the only wiring diagram for the component.exterior lights, defogger systems, which is found in the car Kia K3 II facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
exterior lights, defogger systems wiring diagram (1 of 1)
ACC/
BCW LAMP
BLK WIRE
BLU/ORG WIRE
BRN/BLK WIRE
BRN/ORG WIRE
DEFOGGER
DEFOGGER SYSTEM
DOWN
DOWN/ LEFT
DRIVER POWER OUTSIDE MIRROR
EXTERIOR LIGHTS, DEFOGGER SYSTEMS
GRN WIRE
GROUND DISTRIBUTION SYSTEM
HOT IN ON OR ACC
ICU JUNCTION BLOCK
ICU-D
LEFT
LEFT RIGHT
MODULE 2 FUSE
NAVIGATION SYSTEM
NCA WIRE
OUTSIDE MIRROR
PASSENGER POWER OUTSIDE MIRROR
PNK WIRE
POWER OUTSIDE MIRROR SWITCH
RED/ORG WIRE
RIGHT
SELECTOR SWITCH
TURN LAMP
UP DOWN
UP/ RIGHT
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Power mirror circuit -> EXTERIOR LIGHTS, DEFOGGER SYSTEMS
